CB 3062-79 Four Roller Fairlead Type BB

CB 3062-79 Four Roller Fairlead Type BB

CB 3062-79 Four Roller Fairlead Type BB Fairlead with horizontal rollers, consisting of vertical and horizontal rollers, can guide mooring ropes from any direction. Horizontal roller fairlead, also called universal roller fairlead, is usually located in the deck end. Horizontal roller fairlead can greatly reduce the abrasion of mooring ropes for the rollers fixed around the fairlead.

Send Inquiry

Product Description

CB 3062-79 Four Roller Fairlead Type BB

Fairlead with horizontal rollers, consisting of vertical and horizontal rollers, can guide mooring ropes from any direction. Horizontal roller fairlead, also called universal roller fairlead, is usually located in the deck end. Horizontal roller fairlead can greatly reduce the abrasion of mooring ropes for the rollers fixed around the fairlead.

CB 3062-79 Horizontal Roller Fairlead

CB*3062-79 fairlead with horizontal rollers has 6 types: CB*3060-79 type A, BA, BB, C, D, E. The total number of rollers ranges from 3 to 9. Horizontal roller fairlead is strictly produced according to the standard CB*3062-79. The surface of the rollers do not have any defects which affect its performance and intensity such as cracks, blisters. All the fairleads get the certificate of quality. If you’re interested in our fairleads, please feel free to contact us.

Specification of CB*3062-79 Fairlead Type BB :

Model Type: CB*3062-79 Four Roller Fairlead Type BB

Material: Cast Steel

Standard: CB*3062-79

Roller No.: 4 Rollers

Steel Cable Diameters: 19.5mm~68.0mm

Nylon Rope Diameters: 36mm~100mm

Weight: 155kg~3352kg

Certificate: CCS, ABS, BV, LR, NK, RINA

Drawing of CB 3062-79 Four Roller Fairlead Type BB:

Unit:mm

Steel Rope Dia.

Nylon Rope Dia.

E

F

D

d

L

L1

L2

L3

B

B1

B2

H

H1

Weight(kg)

19.5

36

200

150

100

40-0.5

644

416

300

544

238

194

108

508

250

155

22.5

40

200

150

120

50-0.5

728

456

320

608

280

232

128

552

270

239

26.0

45

200

180

130

55-0.5

776

480

330

646

304

250

138

606

310

306

32.0

70

220

180

150

65-0.5

880

540

370

730

346

288

158

670

330

450

34.5

80

240

200

160

70-0.5

940

580

400

780

370

308

168

710

360

576

37.5

85

240

200

180

80-0.5

1030

620

420

850

417

345

190

770

380

756

43.0

95

260

210

200

90-0.5

1136

686

460

936

459

385

210

820

410

987

52.0

100

260

220

230

100-0.5

1256

746

490

1026

521

445

240

910

450

1370

60.5

_

300

240

260

120-0.5

1430

850

560

1170

590

500

270

1000

500

2008

68.0

_

320

250

320

150-0.5

1690

990

640

1370

714

620

330

1130

570

3352
