JIS F 7372 Cast Rion 5K Swing Check Valves China Marine Cast Iron Swing Check Valve JIS F7372: Design Standard: JIS F7372-1996 Test Standard: JIS 7400-1996 Hydraulic Test Pressure: Body- 1.05Mpa, Seat-0.77Mpa~0.4Mpa Flange size as per JIS B2220 - 5K
JIS F 7373 Cast Rion 10K Swing Check Valves: Marine Cast Steel Screw Down Check Angle Valve also can be called as Marine Cast Steel Angle SDNR Valve or SDNR Angle Valve. It is suitable for the pipe system with the medium fresh water, air & other gas, oil and steam with the temperature not over 300 centigrade degree. Design Standard: JIS F7471-1996 Test Standard: JIS 7400-1996 Hydraulic Test Pressure: Body-2.1Mpa, Seat-1.54Mpa Flange size as per JIS B2220 -10K
JIS F 7371 5K Bronze Swing Check Valves: Design Standard: JIS F7371-1996 Test Standard: JIS 7400-1996 Hydraulic Test Pressure: Body-1.05Mpa, Seat-0.77Mpa~0.4M Flange size as per JIS B2220 - 5K
JIS F 7356 Bronze 5K Lift Check Valves: Design Standard: JIS F7356-1996 Test Standard: JIS 7400-1996 Hydraulic Test Pressure: Body- 1.05Mpa, Seat-0.77Mpa~0.4Mpa Flange size as per JIS B2220 - 5K
JIS F 7359 Cast Rion 5K Lift Check Angle Valves: Design Standard: JIS F7359-1996 Test Standard: JIS 7400-1996 Hydraulic Test Pressure: Body- 1.05Mpa, Seat-0.77Mpa~0.4Mpa Flange size as per JIS B2220 - 5K
JIS F 7417 Bronze 16K Lift Check Globe Valves (Union Bonnet Type) The products are used for controlling the medium to open and close ,preventing refluence in fuel oil piping, lubricating piping.
JIS F 7415 Bronze 5K Lift Check Globe Valves (Union Bonnet Type) 1.Test standard: JISF7400. 2.End standard: JISB2220.
JIS F 7413 Bronze 16K Screw-Down Check Globe Valves (Union Bonnet Type) The valve is used for shipbuilding, ship repair and oil platform with high quality. Dimensions of flange are according to JIS B2220 flange dimensions of steel pipe.
JIS F 7411 Bronze 5K Screw-Down Check Globe Valves (Union Bonnet Type) The products are used for controlling the medium to open and close ,preventing refluence in fuel oil piping, lubricating piping.
