Fire-resistant Armored Marine Control Cables 250V

Fire-resistant Armored Marine Control Cables 250V

Fire-resistant Armored Marine Control Cables 250V ​Application: The cable is intended for power, lighting and control system of shipboard and off-shore building. SPECIFICATION & STANDARDS IEC 60288 IEC60092-376 IEC60092-351 IEC60092-359 IEC60332-1 IEC60332-3Cat.A IEC61034 IEC 60754

Send Inquiry

Product Description

Fire-resistant Armored Marine Control Cables 250V Application:

The cable is intended for power, lighting and control system of shipboard and off-shore building.

SPECIFICATION & STANDARDS

IEC 60288 IEC60092-376 IEC60092-351 IEC60092-359

IEC60332-1 IEC60332-3Cat.A

IEC61034 IEC 60754


Construction:

1. Conductor: tinned copper

2. Insulation: EPR/XLPE

3. Core screen: Tinned copper wire braid

4. Tape

5. Inner sheath: PCP/CSP/PVC/PO (SHF1, SHF2)

6. Armored: tinned copper wire braid

(Galvanized steel wire braid)

7. Outer sheath: PVC/PO (SHF1, SHF2)


Flammability Features:

DA: Single cable flame retardant

SA: Bunched cable flame retardant

SC: Bunched cable flame retardant,halogen-free, low-smoke, low-toxicity.


Specifications:

Cores: 1, 2, 3, 4, 5, 7, 10, 12, 14, 16,19, 24, 27, 30, 33, 37.

Nominal Cross-section Areas: 0.75 mm2,1 mm2, 1.5mm22.5mm24mm26mm210mm216mm225mm2,

35mm250mm270mm2, 95mm2120mm2150mm2185mm2240mm2300mm2.


Certificates:

CCS,LR,ABS,DNV,BV,GL,NK,RINA; 85℃
