Type B Buoy Shackle
  • Air ProType B Buoy Shackle
  • Air ProType B Buoy Shackle
  • Air ProType B Buoy Shackle

Type B Buoy Shackle

Type B Buoy Shackle Buoy shackle type B is one bow type shackle, which is used to connect anchor chains to the mooring buoys.Type B mooring buoy shackle is joined with the end link of anchor chains. It is suitable for grade2 or grade 3 anchor chains. It is made from forged steel or cast steel. The size of it is up to customer’s choice.

Send Inquiry

Product Description

Type B Buoy Shackle
Buoy shackle type B is one bow type shackle, which is used to connect anchor chains to the mooring buoys.Type B mooring buoy shackle is joined with the end link of anchor chains. It is suitable for grade2 or grade 3 anchor chains. It is made from forged steel or cast steel. The size of it is up to customer’s choice.
We supply both type A and B mooring buoy shackles.If you want to know more about our shackles or other marine equipment, please feel free to contact us.

Specification
1. Model Type: Buoy Shackle Type B
2. Material: Steel
3. Grade 2 & Grade 3
4. Nominal Diameter for Chains: 38mm to 90mm
5. Weight: 26kg to 332kg
6. Treatment: Drop Forged or Cast
7. Surface: Hot Dip Galvanized, Self Color
8. Size: Depends on Customer’s Requirement
9. Certificate: CCS, ABS, BV, DNV, KR, RINA etc.

10. Standard or Customized Production are Available
